Kimray Pressure Reducing Package (Diaphragm Pilot) Working Principle | Training Animation

In this video, we look at the production flow through a pressure reducing control valve package, configured with a diaphragm controlled high pressure pilot. Beginning with the valve in a closed position (pressure opening valve, aka fail close), move through the drip pot, supply gas regulator, diaphragm controlled high pressure pilot, and into the control valve actuator. Once the control valve is open, we'll follow the flow into the sense line protector and back into the pressure pilot. 📕 Blog: https://kimray.com/learning/high-pres... 📩 Get Updates: https://kimray.com/subscribe 👨‍🏫 Training: https://kimray.com/services/training 🆘 Support: https://kimray.com/get-product-support ➡️ 1-405-525-4264 or service@kimray.com SOCIAL:   / kimrayinc     / kimray-inc   PODCAST: Apple: https://apple.co/3c82VQd Spotify: https://spoti.fi/2ZMCm0j TIMESTAMPS: 0:00 Intro 0:10 Upstream Pressure & Supply Pressure 0:48 Pilot Plug/Diaphragm Assembly 1:18 Downstream Pressure 1:32 Sense Line Protector 1:54 Vented Diaphragm Pressure 3:03 Drip Pot Drainage 3:12 Other Video Recommendations
