How Jet Engines Work | Part 3: GE90 Turbofan Engine Performance & Control Explained

🔧 GE90 ENGINE EXPLAINED – PART 3: PERFORMANCE CONTROL Welcome to Part 3 of our in-depth exploration of the GE90, the most powerful turbofan engine ever built. In this episode, we focus on Performance Control—the systems that allow this massive engine to think, react, and protect itself in real time. Modern jet engines are not just mechanical machines; they are intelligent systems. At the heart of the GE90 is FADEC (Full Authority Digital Engine Control), a digital brain that continuously analyzes engine data and makes precise decisions within milliseconds. From fuel flow to airflow geometry, every parameter is monitored, calculated, and corrected automatically to keep the Boeing 777 flying safely and efficiently. We break down how compressor stall and surge are prevented using Variable Bleed Valves (VBV) and Variable Stator Vanes (VSV), ensuring smooth airflow even during low-speed or high-stress conditions. You’ll also see how mechanical systems such as the Hydro Mechanical Unit (HMU), torsion rods, and bell crank linkages work together with electronic controls to deliver unmatched precision. Finally, we uncover the secret behind turbine efficiency—Active Clearance Control (HPTACC & LPTACC)—a system that uses controlled cooling air to manage turbine tip clearance, allowing maximum energy extraction without physical contact. 🛠 SYSTEMS COVERED IN THIS EPISODE • FADEC & Electronic Engine Control (EEC) • N1, N2 speed sensors and EGT temperature probes • Pneumatic pressure sensing and intake monitoring • Variable Bleed Valve (VBV) stall protection • Variable Stator Vanes (VSV) and mechanical linkages • Hydro Mechanical Unit (HMU) operation • HPTACC & LPTACC turbine clearance control • LVDT feedback sensors and system redundancy 🎯 WHAT YOU’LL LEARN ✔ How closed-loop engine control works in real time ✔ How jet engines prevent compressor stall ✔ How fuel flow is controlled with extreme precision ✔ Why turbine tip clearance is critical for efficiency ✔ How digital and mechanical systems work together ⏱ CHAPTERS – PART 3 PERFORMANCE BREAKDOWN 0:00 – The Digital Brain: FADEC & EEC 0:42 – Sensor Network: N1, N2 & Temperature Monitoring 1:42 – Pressure Data & Pneumatic Sensing 2:23 – Stall Protection: Variable Bleed Valves 4:08 – Airflow Control: Variable Stator Vanes 6:11 – Efficiency Secrets: Active Clearance Control 7:20 – Precision Feedback & Redundancy 8:00 – Raw Engineering in Motion (No Voiceover) 🔔 SUPPORT THE CHANNEL If you enjoyed this deep technical breakdown, like the video, subscribe to the channel, and turn on notifications so you never miss the next episode in the GE90 series. #GE90 #JetEngine #TurbofanEngine #AviationEngineering #AircraftEngines #JetEngineControl #FADEC #Boeing777 #EngineeringExplained #AerospaceTechnology #CompressorStall #ActiveClearanceControl #MechanicalEngineering #FlightSafety #AviationTech #PlaneMechanics #EngineeringAnimation #AircraftSystems #AviationEducation #TechBreakdown
