सिंगल फेज़ और थ्री फेज़ ब्रिज रेक्टिफायर Single Phase & Three Phase Bridge Rectifier. AC TO DC POWER скачать в хорошем качестве

सिंगल फेज़ और थ्री फेज़ ब्रिज रेक्टिफायर Single Phase & Three Phase Bridge Rectifier. AC TO DC POWER

Single Phase & Three Phase Bridge Rectifier... Your queries:- What is 3-phase bridge rectifier? What is the output of 3-phase bridge rectifier? What is the efficiency of 3-phase bridge rectifier? 3 फेज ब्रिज रेक्टिफायर क्या है? How does a 3-phase bridge rectifier work? 3 फेज ब्रिज रेक्टिफायर कैसे काम करता है? How does a single phase bridge rectifier work? How does a bridge rectifier work? ब्रिज रेक्टिफायर कैसे काम करता है? How does a bridge rectifier work? What is single half full wave rectifier? What is single phase full wave rectifier with RL load? What is the output voltage of single phase full-wave rectifier? What is RF and RL in rectifier? What is a diode used for? We saw in the previous tutorial that the process of converting an AC input supply into a fixed DC supply is called Rectification with the most popular circuits used to perform this rectification process is one that is based on solid-state semiconductor diodes. In fact, rectification of alternating voltages is one of the most popular applications of diodes, as diodes are inexpensive, small and robust allowing us to create numerous types of rectifier circuits using either individually connected diodes or with just a single integrated bridge rectifier module. Single phase supplies such as those in houses and offices are generally 120 Vrms or 240 Vrms phase-to-neutral, also called line-to-neutral (L-N), and nominally of a fixed voltage and frequency producing an alternating voltage or current in the form of a sinusoidal waveform being given the abbreviation of “AC”. Three-phase rectification, also known as poly-phase rectification circuits are similar to the previous single-phase rectifiers, the difference this time is that we are using three, single-phase supplies connected together that have been produced by one single three-phase generator. Three-phase Rectification Having seen that a 3-phase supply is just simply three single-phases combined together, we can use this multi-phase property to create 3-phase rectifier circuits. As with single-phase rectification, three-phase rectification uses diodes, thyristors, transistors, or converters to create half-wave, full-wave, uncontrolled and fully-controlled rectifier circuits transforming a given three-phase supply into a constant DC output level. In most applications a three-phase rectifier is supplied directly from the mains utility power grid or from a three-phase transformer if different DC output level is required by the connected load. As with the previous single-phase rectifier, the most basic three-phase rectifier circuit is that of an uncontrolled half-wave rectifier circuit which uses three semiconductor diodes, one diode per phase as shown. 3-phase Rectification Example No1 A half-wave 3-phase rectifier is constructed using three individual diodes and a 120VAC 3-phase star connected transformer. If it is required to power a connected load with an impedance of 50Ω, Calculate, a) the average DC voltage output to the load. b) the load current, c) the average current per diode. Assume ideal diodes. a). The average DC load voltage: VDC = 1.17*Vrms = 1.17*120 = 140.4 volts Note that if we were given the peak voltage (Vp) value, then: VDC would equal 0.827*Vp or 0.827*169.68 = 140.4V. b). The DC load current: IL = VDC/RL = 140.4/50 = 2.81 amperes c). The average current per diode: ID = IL/3 = 2.81/3 = 0.94 amperes #electrical #diagram #acdc #rectifier? #3-phase #diode [email protected]    / @atozelectricalinformation5590
