Mech Equation: This method is also called as mesh current analysis. In this method, we consider loop or mesh current instead of branch current. For each loop, an equation is written based on Kirchhoff’s Voltage Law KVL and there are a many equations as the number of loops. The current directions are chosen arbitrarily. Procedure:- i) Circulating currents are allocated to closed loops or meshes in the circuit. ii) An equation for each loop of the circuit is then obtained by Kirchhoff ’s voltage law. iii) Branch currents are found thereafter by taking the algebraic sum of the loop currents common to individual branches. Thank you for watching
