Optoma HD142X DLP Projector Repair | Temp LED | Image Flashes Colors| Shuts Down

Optoma 142X DLP Projector repair and cleaning. This was dropped off at my day job after a new lamp did not solve the problem. There was no real symptom given to me. Just that a new lamp had been put in and the projector wasn't working right and asked if we could see why. I'm not sure why he didn't take the last screw out and opted to just rip the top off. It clearly doesn't preserve the warranty. First thing I saw looked like it was an overheating issue, (temp led flashing and fan lock error) but then I see why that happened. Finally I was able to narrow it down to the color wheel sensor. It also needed a cleaning of the optics so I show that towards the end. The cleaning applies to any model that looks like this chassis. This one is a good example of being a little too comfortable. Don't break the housing. Find the missing screw. oh well.. If you need a lamp for this model, use this link and use code YT50 for 5% off and free ground shipping! https://www.purelandsupply.com/optoma... The repair/cleaning process applies to ANY of these following models and brands. Optoma Projector : BR323, BR326, DASSHG, DH1008, DH1009, DS345, DS346, DW333, DX342, DX345, EH200ST, EH330, EH343, EH345, EH346, GT1070X, GT1080, H182X, H183x, HD141X, HD142X, HD26, HD27, HD280S, HT27X, HT3165C, HT38, HT38W, S310e, S310x, S312, S315, S316, S331, VDGTGZBZ, VDHDNL, W300, W312, W316, W330, W331, X312, X315, X316 Acer Projector : H5380BD, P1283, P1283n, P1383W, X113H, X113PH, X133PWH, X1383WH NEC LCD Projector : NP-VE303, NP-VE303X, VE303, VE303X \o/ 00:00 intro 01:33 Fan lock error is unexpected 01:52 Starts over anyway 02:45 check lamp 03:19 5 of 6 screws missing 04:10 damage discovered, wires unplugged 06:12 troubleshooting test 07:54 Cleaning fan, lamp basket removal 16:22 Install cleaned fan for testing 19:47 Test fan/color wheel with multimeter and scope 21:58 Color wheel issue detected 26:48 Color wheel sensor filthy 28:20 Color wheel sensor clean 30:19 Testing after cleaning 32:00 Repair screw tower 37:35 Initial assembly for testing 48:34 First video test 49:00 Dust in optics 49:48 disassembly for cleaning 53:29 Open cleaning port on optic assembly 59:46 Replace tape for final assembly 1:04:30 Re-repair plastic screw tower for case with CA and epoxy 1:08:23 Science 1:10:52 Screws for the last time 1:12:42 Final test
