Northern England chemical plant - point cloud and Aveva PDMS model

This was a relatively large chemical plant located in the north of the UK. Initially the client commissioned a point cloud survey to be registered and delivered along with TruView in RGB (real colours). Subsequently the client came back and commissioned an as built PDMS model with catalogue, specifications and custom generated ISO drawings. Following further commissions we have now completed a full PDMS model for the entire site. Further to surveying and modelling at this site, we undertook further digital analysis works including clash detection for new installations, Tank leakage analysis and provided recommendations for the installation of barriers and Bunds to limit the extent of fluid leakage. More information: https://www.3deling.com/portfolio-ite...
