[Best Modules] How to use the Holtek 8-bit MCU Debug Adapter e-Link?

📌 Holtek 8-bit MCU Debug Adapter e-Link 💻More Information: https://www.bestmodulescorp.com/e-lin... 00:00 00:04 Opening 00:05 00:10 How to use the Holtek 8-bit MCU Debug Adapter e-Link? 00:11 00:28 Pin Description 00:29 00:35 Mode Selection 00:36 00:57 Program→HOPE3000 For e-Link 00:58 01:17 Debug Program→HT-IDE3000 / OCDS 01:18 02:04 How to program the file with the e-Link? 02:05 02:20 www.BestModulesCorp.com ✒Description The e-Link is an online debug adaptor for Holtek's new generation of OCDS architecture 8-bit Flash MCUs. Together with the HT-IDE3000 software it allows users to program and debug programs on their target boards. ※The e-Link only supports OCDS architecture 8-bit Flash MCUs. ※For each new e-Link being used for the first time, it must be enabled by using the activation program. The e-Link also provides an ICP function for 8-bit Flash MCUs. When connected to a PC and when used together with the HOPE3000 software the e-Link can also be used as a low volume engineering programmer for HT8 Flash MCUs. ※The e-Link is not able to support offline programming and is not suitable for volume device programming. ※The e-Link does not yet support programming of the Boot Loader ROM code program. As a result it should not be used for programming application programs which have an ISP requirement such as the HT6XFB5X0. ✒Product Information ◆Dimension: 84mm x 44mm x 13mm ◆Weight: 91 g ◆Packing List: e-Link x 1、Flat-Cable (e-cable1225A) x 1、Mini USB Cable x 1、e-FPC06A x 1、2×6 Pin Double-Row Male Headers x 1、Important Information x 1 🏢 Best modules corp. 🔗NO. 3, Creation Rd. II, Science Park, Hsinchu 30077, Taiwan 🤝service@bestmodulescorp.com #8-bitMCUDebugAdaptere-Link #Adaptere-Link #e-Link #MCUDebug #ICEStarterKits #DevelopmentTools #OCDSarchitecture #OCDS #FlashMCU #ICPfunction #HT-IDE3000 #Holtek #easyBurn #easyUse #MCU調試適配器e-Link #調試適配器e-Link #線上偵錯調適器 #偵錯的MCU開發工具 #開發工具 #模擬器 #開發套件 #OCDS架構 #HT-IDE3000 #Caca愛吃好心情 #Caca愛跟風 #Jessicaca256 #JessicaChiang #Jessica.ca.25
