Qinsun Automatic Bursting Tester | Bursting Strength Tester

The Automatic Bursting Strength Tester is a hydraulic diaphragm-type testing instrument used to determine the bursting strength, bursting pressure, bursting height, and bursting time of textile and flexible sheet materials. The tester applies uniform hydraulic pressure beneath an elastic membrane, causing the specimen to deform and burst. The pressure and deformation parameters at the moment of rupture are recorded automatically. Inquiry：serving@qinsun-lab.com https://www.qinsun-lab.com/Products/ The instrument adopts intelligent control algorithms to precisely regulate the pressurization process and bursting time. Both manual and automatic control modes are available. A PC-based control and data processing system enables easy operation, data analysis, and report printing. The tester supports all standard-required test areas and fully complies with the requirements of different international and domestic standards. Application： Woven fabrics Knitted fabrics Nonwoven fabrics Paper and paperboard Corrugated board Packaging materials Films, membranes, and sheet materials Standards： ASTM D3786,ERT 80-4-20,GB/T 7742.1,BS EN ISO 13938-1,BS 3424-6-B,ISO 3303-B,ISO 2758,ISO 3303-2,ISO 3689,JIS L1018 / JIS L1093,IWS TM170,FZ/T 75003-1993 Parameters： Measurement Range 1%–100% of full scale Maximum Pressure Range Up to 6.000 MPa Resolution 0.002 MPa Elastic Diaphragm Size Outer diameter φ80 mm Diaphragm Thickness 0.9 ± 0.1 mm Test Cup Sizes φ112.8 ± 0.2 mm (100 cm²) φ79.8 ± 0.2 mm (50 cm²) φ35.7 ± 0.2 mm (10 cm²) φ31.5 ± 0.2 mm (7.5 cm²) φ30.5 ± 0.2 mm (7.3 cm²) φ30 ± 0.2 mm Maximum Bursting Height 70 ± 0.02 mm Maximum Bursting Time 99.9 ± 0.1 s Pressurization Rate 100–500 ml/min, manually adjustable or intelligent automatic control Features： Supports full test area configurations to meet different standard requirements, including GB standard maximum test area of 100 cm² Pneumatic clamping system provides uniform and stable holding force for various materials Intelligent control algorithm ensures accurate pressure application and bursting time control PC connection for data acquisition, statistical analysis, and test report printing Multiple result display modes including bursting strength, bursting force, diaphragm pressure, bursting height, and bursting time
