Cheap USB to UART (RS232/Serial) Converter Using Microchip MCP2200

Cheap USB to Serial (RS232/UART/TTL) Converter Circuit using Microchip MCP2200 In this video, I talked about a USB to Serial/RS232/UART/TTL converter circuit. The most common way of converting USB to serial (Virtual COM port) is to use FTDI chips such as FT232. FTDI chips are good, nothing wrong with them, however, there is another option with Microchip that has offered the MCP2200 USB to serial/RS232/UART/TTL converter IC. The circuit has been tested, schematic and PCB are also available. To decode the RS232/Serial/UART/TTL data, I used the Siglent SDS2102X Plus oscilloscope. However, You can use the Siglent SDS1104X-E oscilloscope to decode the serial/RS232/UART/TTL as well. I prefer this MCP2200 over FTDI USB to serial converter or USB to RS232 converter circuit. So this is an MCP2200 USB to serial converter. You can also use this for Arduino serial communications using UART. ========================================== Altium Designer: https://www.altium.com/yt/myvanitar ========================================== Article: https://www.pcbway.com/blog/technolog... ========================================== Check other videos: http://bit.ly/2N9OlPa ========================================== Tools Siglent SDS2102X Plus: https://www.siglenteu.com/digital-osc... ========================================== Inspired by: Julian Ilett Arduino USB-to-Serial Tutorial - Programming the Pro Mini URL:    • Arduino USB-to-Serial Tutorial - Programmi...   Inspired by: Gal Kremer How To Connect An FTDI Adapter To A UART Port URL:    • How To Connect An FTDI Adapter To A UART Port   Inspired by: Adafruit Industries USB, serial & you...    • USB, serial & you...
