Straightening leadscrew

The 8mm diameter leadscrew that I ordered was delivered to me slightly bent, which was quite understandable because it was rather long. In order to straighten it back, I fabricated a cam handle so that a manually controlled force could be applied at several specific spots identified. The force was applied through a piece of hardwood so that it would not damage the screw threads. Also the straightening process could be stopped before it could be over-bend. The bend curve of the leadscrew naturally come to rest on its side. Stepped clamps were fastened at the ends with the high spots in between. The cam handle was used to push at it with a controlled force. More information could be found at www.divinemercylamp.com/yoon
