How do I join two aluminum profiles at any angle using the item Mitre-Butt-Fastening Set?

How do I join two aluminum profiles at any angle using the item Mitre-Butt-Fastening Set? In this video, we show you step by step how to assemble two aluminum profiles using the item Mitre-Butt-Fastening Set. The Fastener is suitable for mitre angles γ between 30° and 90°, allowing the profiles to form angles between 60° and 180° to each other. This video shows you the production steps using the Line 8 as an example. For which Lines is the Mitre-Butt-Fastening Set available? Line 6 in the Standard and Light variants, with open and closed t-slots Line 8 in the Standard, Light and E (Economy) variants, with open and closed t-slots Line X 8 The video is divided into the following steps: 00:00 Intro The intro uses a title image showing a screenshot from the video in which a screw of the Mitre-Butt-Fastening set is being tightened. 00:04 The mitre cuts of the profiles are deburred. 00:13 The profiles are clamped in the drilling jigs for the lateral holes. 00:26 The depth stops for the drill bits that will produce the lateral holes are set. 00:41 The lateral holes are drilled on a pillar drill. 00:50 The holes perpendicular to the cut surface are drilled. We recommend using the appropriate drilling jigs for this operation. As a tool we recommend a cordless drill. 01:11 The threaded sleeve is inserted and the clamping pin is screwed in up to the marking. Turn the clamping pin in until the circumferential groove is flush with the cut surface. Then turn the clamping pin back out until the flat face inside the sleeve is visible through the bore. 01:38 The clamping pin is secured with the grub screw. 01:58 The sleeve with bore is inserted and the profiles are joined together. The grub screw then clamps the clamping pin. Tighten the grub screws to the specified tightening torque. 02:20 The scene shows how the conical recesses of the clamping pin are correctly positioned. 02:30 The video shows a fully assembled profile frame. Which item components are used in this video? Profile 8 40x40 2N90 light, natural: http://i24.ws/40450 Mitre-Butt-Fastening Set 8: http://i24.ws/49225 Drilling Jig, Mitre Connection 8 D14.2: http://i24.ws/49225 Step Drill, Mitre Connection 8: http://i24.ws/49260 Drilling Jig, Mitre Connection 8 D9: http://i24.ws/49260
