How do I install freestanding enclosures and guards with the item Stand Foot Set 8 St 160x160?

A smart solution for safe stability! Stand Foot Set 8 St 160x160 (0.0.699.95) combines optimum protection with a compact design and is ideal for use with freestanding enclosures and guards. It enables a cost-effective and robust floor fixing while also supporting a range of safety concepts. Profiles 8 80x40 or Profiles 8 40x40 are used as the stand profiles, or posts, for protective enclosures and guards. These profiles are fastened to the stand foot by screwing the fixings supplied in the Stand Foot Set into the grooves of the profiles. Two Screw Anchors ST 10x110, bright zinc-plated (0.0.688.05) are the ideal fixings for anchoring the entire construction to the floor. The lower fixings of the Stand Foot Set can be installed in two different ways. While driving them through the drilled holes creates a rigid, mechanically locked connection, using the slot instead ensures the upright posts of the guard can be easily aligned. When located in the slot, the screw fixings can help to cushion an impact by dynamically absorbing the force by means of friction resistance. Major collisions also leave clearly visible evidence. As a result, the enclosure or guard is more likely to be checked for damage, repaired with spare parts and then restored to full working order. Thanks to its bright zinc-plated surface, the product can also be used with ESD-safe enclosures and guards. This instructional video guides you step by step through the assembly of the stand foot. 00:00 Intro 00:04 Drill holes in the floor for the stand foot 00:31 Prepare profile 00:37 Pre-assemble stand foot 01:46 Anchor stand foot in floor 02:03 Adjust stand foot
