Legend Tool: How to Organize Your Measurements on Drawings

In this video, I’ll show you how to use the Legend Tool to bring order to your project drawings. If you’ve ever felt like your 2D plans were becoming a "cluttered mess" of measurements, this is the solution you’ve been looking for. I’ll walk you through exactly how to set up a professional breakdown for floors, ceilings, and walls, ensuring your data is readable in both 2D and 3D views. What you’ll learn in this tutorial: Placement: How to add a legend and specify the insertion point. Smart Grouping: Using "Show Groups" and "Show All Groups" to mirror your Measurement Manager. Detailed Breakdown: Toggling "Show Measurements" for a complete list of every take-off. Custom Columns: Choosing the right data points, including Area, Perimeter, and Length. Style & Visibility: Adjusting Scale and Opacity so the legend doesn't block your plan. Dynamic Themes: Seeing how the legend automatically adapts to Light/Day Mode. Management: How to move, resize, and delete legends to keep your workspace clean. This tool is a game-changer for anyone who needs to present organized, professional-grade estimation data directly on their blueprints. Subscribe for more professional tips on mastering your construction measurement and estimation tools!
