How To Check & Replace Heating Elements On The 112 Extreme I Miller Weldmaster

Website: https://www.weldmaster.com Machine Page: https://www.weldmaster.com/112-extreme This video will be going over how to check and replace your heating elements on your 112 Extreme machine. 00:25 Before Replacing Heat Element 00:40 After Disconnecting All Power 00:51 How To Remove Parts of Element Housing 01:24 How To Remove Heat Elements 01:50 How To Install New Heat Elements 01:56 How To Reinstall Parts of Element Housing 02:48 If You're Having More Issues Although longer heat element life is possible with proper maintenance, the heating elements used by Miller Weldmaster are rated for 1000 hours at 730 degrees Celsius. In the event the heat elements fail prematurely contact a Miller Weldmaster representative before replacing. Before replacing your heat elements, you will want to make sure that your machine is DISCONNECTED from the power source and the circuit breaker on your machine is turned to the OFF position. You will also need to unplug machine if possible, in order to perform this task in a safe manner. After safely disconnecting all power connections you can begin by first unplugging both of the thermocouple leads. Remove thermocouple wire mounts. Remove top covering of the element housing and slide it out of the way. Remove the rubber insulation between the wire leads and the aluminum air divider. Remove the 4 leads from the heat elements. Loosen the 4 screws securing the aluminum air divider and remove the aluminum air divider. CAREFULLY remove each heat element from the element housing. Inspect each element for any broken off fragments of glass or wire. Any missing fragments will be in the dual element housing or nozzle. These fragments MUST be removed prior to installing new heat elements. CAREFULLY install new heat elements in the dual element housing. Install the aluminum air divider. Connect the four wire leads to the elements. Make sure wires #1 and #3 are connected to the same element and wires #2 and #4 are connected on the other element. Insert the 2 pieces of insulation between the wire and the aluminum air divider. Slide the top covering back onto the heat element housing. Make sure to feed the thermocouple connections through the top hole. Install the 3 sheet metal screws to the top of the heat element housing. Connect the thermocouple wire leads and test heating function. If the temperature controller starts reading backwards, flip the leads. Want to learn more? Visit our website below or email us at sales@weldmaster.com Facebook:   / millerweldmaster   Linkedin:   / miller-weldmaster   Instagram: https://www.instagram.com/millerweldm... Twitter: https://twitter.com/weldmaster?lang=en Music Info: Soft Inspiring Corporate Uplifting Ambient by RomanSenykMusic. Music Link:    • Soft Inspiring Corporate Uplifting Ambient...  ​ #fabricwelding #pvcwelding #millerweldmaster
