Automated Tube Forming System for HVAC OEMs | Reduce Labor & Increase Throughput-Winton Tube Bending

This automated tube forming system helps HVAC and refrigeration OEMs reduce labor dependency, improve consistency, and increase throughput in high-volume tube fabrication. Automated Tube Forming System for HVAC & Refrigeration OEMs This automated tube forming system helps HVAC and refrigeration OEMs reduce labor dependency, improve consistency, and increase throughput in high-volume tube fabrication. Designed for manufacturers working with aluminum and copper tubing, this rotary transfer tube forming automation integrates multiple forming operations into a compact, repeatable production cell ideal for OEMs facing skilled labor shortages, rising copper costs, and growing demand. What this tube fabrication automation solves: Reduces manual tube forming and handling Improves repeatability and part-to-part consistency Increases throughput without adding headcount Lowers scrap in copper and aluminum tubing Supports high-mix or high-volume OEM production Common applications: HVAC OEM manufacturing automation Refrigeration and heat exchanger production Condenser and evaporator tube forming Copper line set manufacturing Tube end forming and multi-station tube operations This rotary transfer tube forming system is built for OEMs looking to move from manual or semi-automated processes to scalable, labor-saving manufacturing automation with a small footprint and strong ROI. MODEL #: 05-10 See all the Specifications: https://www.wintonmachine.com/tube-fa... ----------- RT23 Forming System – Cut, End form, and Bend in One system to include: Seven (7) axis electric servo forming system, straighten + cut + end form + bend + unload Windows Professional PC user interface with program storage System pulls from a level wound vertical coil – payoff not included Horizontal powered transfer roll dies and vertical powered straightener section Pull-apart type chipless cut for minimum burr to the inside of the tube Three (3) axis servo pick-n-place with pneumatic gripper to transport cut tube Single hit ram end former with automatic lube Clockwise Ø23mm tube OD capacity with dual stack rotary draw CNC bend head Two (2) axis electric servo carriage with boost + Electric bend head Pneumatic pick-n-place for unloading of formed tubes into customer supplied bin Oil containment for end former with user friendly drain Light tower status indicator – lets operator know the status of the system Box guarding with electrical interlock 80 PSI shop air required TRAINING: Two (2) Days at customer’s facility (US or Canada)
