Electric CNC Tube Bender | RD10 Tube Benders by Winton to Increase your Dollar per SQ-FT floor Space

RD10 CNC tube bender for small diameter tubing including brake lines, refrigeration components, and fuel lines. Production ready, this three-axis all-electric tube bender uses a Windows-based interface for operator control. The machine comes standard as a single radius CNC tube bender. An optional dual stack bend head allows a user to bend tubing using two different radii. The RD10 bends stainless steel up to Ø10mm (3/8”) using a rotary draw process. This technique has proven to be effective for tight radius bending. The collet closer that holds the tubing during the bending process makes use of 80 PSI shop air. This ensures the tube is help tight before, during, and after a plane rotation. The design of the carriage spindle allows the end of the tubing to get right up next to the bend tooling on the very last bend. This often translates into avoiding a trimming operation after bending. Software features include hitch feed, pause before bend, XYZ to LRA conversion, interference checking, 3 axis per bend speed settings, and more. An optional STEP file converter allows a user to read in a CAD generated STEP file direct from CAD right into the bender’s controller. No need to type in the tube’s bend data standing at the RD10, add the 3 dimensional bend data direct from your CAD system. Collision Detection & Bend Simulation Software Enhance your productivity by upgrading to Winton’s new Collision Detection and tube bend simulation Software. By implementing advanced 3D modeling and real-time motion simulation to prevent costly crashes during CNC tube bending, allowing users to visualize the bending process before it occurs on the machine. View the real-time bending process (cycle time) and alerts the user if the bent profile interferes with the machine. Our software improves repeatability, eliminates rework, and protects your capital equipment investment. Automatically simulates every bend before production begins. Detects potential interference between tooling, carriage, and tube geometry. Supports multi-stack bending setups. Reduces setup time and operator trial/error adjustments. Improves first-part accuracy and short-run profitability. Compatible with 3D STEP import, letting engineers validate bends directly from CAD models. MODEL #: 21406 01-18 See all the Specifications: https://www.wintonmachine.com/tube-fa... TAGS: Winton Machine, CNC Tube Fabrication, automatic tube cutter, tube cutting machine, programmable cut length, chipless cutting, copper tubing, aluminum tubing, stainless steel tubing, automatic feed and cut, production tube cutting, microprocessor controlled, electric servo feed, multi-roll straightener, industrial tube processing, batch processing, precision tube cutting, automatic unload, tubing clamp, industrial automation, high-speed tube cutter
