Structural Engineering & Construction Situation 30 (PH)

PAST BOARD EXAM PROBLEMS Structural Engineering & Construction Situation 30 To prevent the ladder from sliding down, the man exerts a horizontal force at C. Given: L1 = 4.5m, L2 = 1.5m, ⌀ = 30° 1. Find the horizontal force at C, which the man should exert if the weight of the ladder is 500 N. Assume that surface A and B are frictionless. (577.7 N) 2. If the weight of the ladder is 500 N, what is the reaction at A? Surface A and B are frictionless. (500 N) 3. Find the maximum weight of the ladder that can be held from sliding if the man exerts force C = 200 N. Coefficient of friction at A is 0.30 and at B is 0.20. (421 N). Credits: 1. Intro Template:    • (FREE) 2D Square Intro (60 fps - No Text) ...   2. Music: 2.1 Driven to Success by Scott Holmes, Source: http://www.freemusicarchive.org 2.2 Instrumental (Guitar) by Carl Ernest Tayag, check his channel:    / @ninja35ful   3. Reference for the problem: Civil Engineering Reference for Licensure Examination, Volume 4, 1st Edition by DIT Gillesania (GERTC Review). Comment your suggestions or questions here. Thanks for watching! Subscribe now for more videos and click the bell icon for notifications. God bless! :) #SEC #CEBox #CivilEngineering #Engineering #ceboardexam #boardexam #prc #review #CivilEngineeringLicensureExam #structuralengineering #stem #engineeringlife #stemlife
