BROWN & SHARPE UNIVERSAL I.D./O.D. CYLINDRICAL GRINDER -2

More info on our website: http://www.machineryvalues.com/xdetai... 14" X 30" BROWN & SHARPE (MADE IN USA) "HIGH PRECISION" UNIVERSAL I.D./O.D. CYLINDRICAL GRINDER MODEL: #1430U S/N: 521-1430-152 NEW: 1980 NOMINAL SWING ..................................... 14" DISTANCE BETWEEN CENTERS, NOMINAL ................. 30" DISTANCE BETWEEN CENTERS, MAXIMUM ................. 33-3/4" SWIVEL TABLE, SCALES FOR ANGULAR SETTING .......... 11 DEG. BACK 3 DEG. FORWARD TAPER PER FOOT ....................... 5" BACK 1-1/2" FORWARD WHEELHEAD MOTOR ................................... 5 HP WHEELHEAD SPINDLE SPEEDS (3) ...................... 1600, 2000 & 2400 RPM WHEEL SIZE ........................................ 14" X 1-1/2" X 5" WHEELHEAD SWIVELS LEFT & RIGHT OF CENTER .......... 90 DEG. WHEEL SPINDLE SWIVELS ............................. 90 DEG. HEADSTOCK MOTOR ................................... 1/2 HP HEADSTOCK SWIVELS ................................. 180 DEG. INFINITELY VARIABLE SPINDLE SPEEDS ................ 25 TO 500 RPM SPINDLE NOSE ...................................... A2-6" INFINITELY VARIABLE TABLE SPEED ................... 3" TO 150" IPM TRAVEL PRE-REVOLUTION OF HANDWHEEL ................ 0.1" SLOW 1" FAST DWELL @ TABLE REVERSAL ............................ 0 TO 2-1/2" SECONDS SWIVEL TABLE - TAPER PER FOOT ..................... 5" BACK 1-1/2" FORWARD SCALES FOR ANGULAR SETTING ......... 12 DEG. BACK 3 DEG. FORWARD AUTOMATIC CROSS FEED, INF. VARIABLE ............... 0.0001" - .003" POSITIVE STOP SETTING ............................. 0.00002" HAND FEED PER REV. OF HANDWHEEL ................... 0.1" SLOW 0.3" FAST APPROXIMATE MACHINE WEIGHT ........................ 8,400 LBS APPROXIMATE DIMENSIONS ............................ 95"L X 77"D X 61"H MACHINE FEATURES: HYDRAULIC OPERATION WITH POWER TABLE TRAVERSE AUTOMATIC INFEED .... POWER CROSSFEED ADJUSTABLE TO 0.000050" POSITIVE CROSSFEED STOP ADJUSTABLE WITHIN 0.000020" RIGHT OR LEFT END WHEEL MOUNTING DOUBLE SWIVEL WHEELHEAD - SWIVELLING @ WHEEL SPINDLE HEAD OR AT THE WHEEL SLIDE PERMITS ANY COMPOUND SETTING REQUIRED IN COMBINATION STRAIGHT AND TAPER GRINDING DUAL DEAD/LIVE HEADSTOCK SPINDLE PULL-OUT HYDRAULIC SYSTEM WITH HEAT EXCHANGER/COOLER 3/60/230-460 VOLT MOTORS EQUIPPED WITH: B & S SWING DOWN I.D. GRINDING ATTACHMENT WITH B & S I.D. SPINDLE MAGNETIC CHUCK COOLANT TANK & PUMP "ELECTRALIGN" ELECTRONIC READOUT FOR TABLE SWIVEL MEASUREMENT MACHINE WAS WIRED FROM THE FACTORY AT 230 VOLTS BUT HAS BEEN CHANGED. THE MACHINE IS PRESENTLY SET UP TO RUN ON 3/60/460 VOLTS. INSPECT UNDER POWER IN OUR HARRISON, NJ WAREHOUSE * ** EXCEPTIONAL CONDITION & APPEARANCE - FROM A QUALITY TOOLROOM **
