NO Sensor to NC Sensor Circuit Wiring/Connection II Proximity Sensor Wiring (MY2N-GS)

PNP-NO Sensor can be converted in PNP-NC Proximity sensor by using OMRON MY2N Relay. NO NC is the operation method in proximity sensor wiring/connection, Use a Electromechanical relay to convert PNP-NO to PNP-NC or NPN-NO to NPN NC. This method is useful in capacitive sensor, inductive sensor and photoelectric sensor.NO NC kya hota hai? Please follow steps to connect NO-type sensor to NC-type Sensor For Ordering Sensors, Controllers, Timers, Counter. Buy at Discounted Rates at: https://made2automate.com/ (Circuit Diagram also Available for Free) *************************************************************************************** What is NO-NC in Switches and in Sensors?    • NO NC Wiring Switch/Proximity Sensor & in ...   What is PNP/NPN type in sensors?    • What is NPN and PNP Sensor Output?   How to Connect PNP/NPN sensor to relay and Motor?    • How to Connect Sensor PNP/NPN with Relay a...   ************************************************************************************** (Definition) What is NO contact? A NO contact or a normally open contact is the one that remains open until a certain condition is satisfied. For example, let us consider a limit switch. A limit switch consists of at least one NO contact in it. The NO contact in the limit switch remains open until its actuator is pressed. When the actuator is pressed the contact closes and starts conducting. In the case of proximity switches, NO contacts remain open until it senses some object similarly in the case of pressure switches, the contact remains open until the preset pressure level is reached. What is NC contact? A NC contact or normally closed contact is the exact opposite of NO contact by function. It remains closed until a certain condition is satisfied. Let us discuss the operation of the limit switch in this case. The NC contact of a limit switch, when used in a circuit breaks the circuit or current flow when its actuator is pressed. Similarly, the contacts of a relay remain closed unless its coil is excited. ********************************************************************************************** Please Like and Share the video: -Sparrow
