5th session of E3D (Equipment Modeling-Part 2)

*🛠️ AVEVA Everything3D Course - Episode 5: Equipment Modeling Mastery with Ali! 🚀* Welcome to the 5th session of the AVEVA Everything3D Course, led by Ali! In this episode, Ali will guide us through the intricate process of modeling a piece of equipment. Let's dive in! *Step-by-Step Equipment Modeling:* 1. *Choosing the Right Level:* Ensure you're on the appropriate level for equipment modeling. 2. *Creating Equipment:* Click on the equipment icon in the EQUIPMENT tab or right-click on the drawlist and select EQUIPMENT to open the Equipment creation window. Specify the name, position, and attributes for the equipment. Press OK to continue. 3. *Creating Sub-Equipment:* Organize your equipment modeling by creating sub-equipment for categorizing primitives such as body, support, nozzles, and insulation. Use the menu or right-click options to create sub-equipment. Name the sub-equipment and maintain the position relative to the main equipment. 4. *Primitive Modeling:* Choose from a variety of primitives such as Box, Cylinder, Cone, and more. Begin by creating elements for the sub-equipment "BODY," which may include dishes and cylinders. Use the PowerCompass tool to orient primitives perpendicular to the desired plane. Utilize additional functionality options to specify locations and dimensions accurately. Experiment with maneuvering in E3D using the Middle Mouse Button (MMB) for zooming, rotating, and panning. 5. *Copy Mirror Technique:* Duplicate primitives using the Copy Mirror tool found in the HOME tab under the Create category. Select the element to copy, choose the origin for mirroring, specify the direction, and apply. Congratulations on completing this session! 🎉 You've acquired valuable skills in equipment modeling using AVEVA E3D. Practice these techniques to enhance your proficiency, and stay tuned for the next episode where we'll explore creating sub-equipment "support" using Move commands. Thank you for joining us on this educational journey with Ali! Keep learning, keep creating, and see you in the next session. ✨ #AVEVAE3D #EquipmentModeling #Engineering #Education 🌐
