Webinar | String Control Techniques (Parking Bay)

Civil Site Design boasts a range of tools to assist with designing Strings that are independent but referencing other strings or surfaces. V22 was released earlier this year with some updated and improved tools to assist with these design processes, namely Surface Extend and Auto Profile (found in the Vertical Grading Editor). In this webinar we will be unpacking some of the features of these tools and demonstrating how you can utilise them to connect your strings together, creating simple parking bays adjacent an existing road in the process. Topics covered: 0:00 Introduction 9:29 Template overview 10:14 Parking Bay kerb creation 11:55 Using Model Builder 17:37 Using updated String Code Surface Extend 21:20 Auto Profile updates 23:28 Using Grips with your Civil Site Design surfaces and models 24:20 Updating Auto Profile entries with VGE Refresh 25:55 Dish creation 37:08 Creating Threads to connect the design 44:20 Plotting a Built Model 46:30 Unpacking Reference Point 55:14 Using Project Assist Civil 3D data sets for the webinar can be found here: https://storage.civilsurveysolutions.... (PLEASE REVIEW THE .TXT FILE BEFORE OPENING THE DATA SETS)
