How to Use Circular Pattern in Autodesk Fusion for Fast Parametric Designs

Learn how to use the Circular Pattern tool in Autodesk Fusion to quickly repeat cuts and features around an axis. In this tutorial, you’ll sketch a simple shape, extrude a cut through the body, then use Create Pattern - Circular Pattern to pattern the feature evenly around your model. You’ll also see why patterning features (instead of bodies) is often the best workflow, and how editing your timeline first (adding fillets and chamfers before the pattern) can save a ton of clicks while keeping everything parametric. Finally, we’ll edit the circular pattern to include additional features and show how a single change updates the entire pattern automatically. Chapters 00:00 Circular Pattern overview in Autodesk Fusion 00:14 Sketch setup on the circular face 00:29 Construction line and constraints to the origin 00:42 Extrude cut settings (distance: All, operation: Cut) 00:55 Create Pattern - Circular Pattern command 01:08 Pattern type: Features, select the axis, set quantity 01:22 Resulting patterned cut and design variations 01:35 Add fillets before the pattern to avoid repetitive clicks 01:46 Add chamfers to top edges before patterning 02:09 Why the pattern only includes selected features 02:23 Edit circular pattern and add more features (Ctrl or Command select) 02:44 Parametric update demo by editing a feature dimension 02:56 Wrap-up: faster modeling with feature patterns What you’ll learn When to use Bodies vs Features in Circular Pattern How to choose an axis and set pattern quantity Timeline strategy: add fillets and chamfers before the pattern How to edit a circular pattern to include additional features How parametric updates propagate through the full pattern #autodeskfusion #fusiontutorial #CAD #parametricdesign #3dmodeling
