Blueprint Bootcamp – BB 5 Offset Flange Bolt Holes Out of Line

BB-5 – Offset Flange | Bolt Holes Out of Line is live! In this Blueprint Bootcamp workout, we take on an Offset Flange with bolt holes that don’t play by the rules — testing your ability to think beyond symmetry and accurately place features in unconventional layouts. Download the PDF here https://drive.google.com/file/d/1aARZ... You’ll practice: ✅ Positioning hole patterns that aren’t centered or evenly spaced ✅ Managing symmetry and offset distances in sketches ✅ Building from 2D to 3D with precision and intent 💬 Challenge Question: Can you rebuild this drawing without assuming symmetry — and still nail every bolt hole location? 📌 Sign up for Onshape for free and get up to 6 months of Onshape Professional: ➡️ http://onshape.pro/MesaMakes 🧠 Need to brush up on your sketching skills? Start with the Onshape Orientation series ➡️    • Onshape Orientation – 2D Sketching Fundame...   ⚙️ Level up your 3D skills: Watch the Shifting to Solids series ➡️    • SHIFTING TO SOLIDS-ONSHAPE 3D TOOLS   📘 Grab the 2D Practice Packet: https://www.teacherspayteachers.com/P... 🧢 MesaMakes Merch: https://mesa-makes-shop.fourthwall.com/ 📺 Subscribe for new Blueprint Bootcamp drops every Monday! ➡️    / @mesamakes
