RF elements® Twin Horn Bracket Product Introduction

RF elements® Twin Horn Bracket (THB) is designed for quick and easy installation of two RF elements Symmetrical Horns ( https://bit.ly/2OFxJ4U ) with the exact same azimuth and elevation. Product page: https://bit.ly/3tTkNIx Datasheet: https://bit.ly/3gvVZ5w Where to buy: https://rfelements.com/stock-locator/ UBR ring fix video:    • RF elements UBR Bracket Ring Assembly   THB lets you aim two horn sectors at one, super-dense area with exactly the same azimuth and elevation. There are many ways to use the THB with two horns. You may be looking to add more capacity to your existing sector and use a different channel with each antenna (symmetrical horns cover 1300 MHz of bandwidth). With the additional channel, you may even decide to use different radio platforms offering higher grade service for the interested customers. Maybe, you want to have a simple and elegant solution for a redundant AP on a site - with THB and additional horn it is a very easy and economical solution. Combinations of Horns, interfaces and radios are almost endless. RF elements® Symmetrical Horns come with TwistPort™ and N-connector interface. Using THB with the TwistPort™ horns you have two options: 1. You can use SMA adaptors and connect them to the radio with pigtails. If you are using Cambium ePMP3000 or Mimosa A5C radios, you can mount the radios directly with the horns on the THB. Any other 4x4 or 2x2 radios must be mounted on the tower. You can use TwistPort™ adaptors we offer for Cambium, Ubiquiti, Mimosa, and MikroTik radios. But make sure beforehand there is enough space to fit two TPAs with radio - the list of compatible radios: UBNT: Rocket Prism 5AC, Rocket Prism 5AC Gen 2, AirFiber 5X, AirFiber 5X HD, LTU Rocket, PrismStation 5AC, IsoStation 5AC, IsoStation M5, Rocket M5, Rocket 5AC Lite Cambium Networks: ePMP 2000 AP Mimosa Networks: Mimosa C5c, Mimosa C5x, Mimosa A5x Mikrotik: all boards that fit in TPA-RBC and TPA-RBP 2. If you have Symmetrical horns with the N-connectors, the installation is straightforward - use any of the two bracket profiles with the four-connector radios, or any other radio attached to the tower. Installation is easy. Before climbing the tower, it’s a good idea to attach the antennas and the radio to the bracket body while on the ground - the comfortable handle makes it easy to attach to a harness. Install the pole mount on the pole and simply slide the bracket in the position. Now you can aim the bracket - the azimuth and elevation measures are easy to read. Once done, simply tighten the azimuth and elevation bolts, and you’re ready to rock! 0:00 Intro 0:25 Package content 0:35 Use scenarios 1:27 Using THB & TwistPort horns 2:09 Using THB & N-connectorized horns 2:29 THB tower Installation #RFelements #Make5GHzGreatAgain #WISP #SymmetricalHorns #TwistPort #wirelessbroadbandinternetaccess #wirelessinternetservices #wirelessbroadbandinternet #fixedwirelessaccess #fixedwireless #wirelessISP #ISP #ruralinternet #ruralbroadband #broadband #UBNT #wirelessinternetservices #internetserviceprovider #broadbandinternetprovider #WirelessRadio #unlicensedbands #TwinHornBracket
