REID Lifting T DAVIT Winched Assembly Video

An extensive range of davits offering up to WLL 500kg with 360° rotation under finger tip control for those difficult locations, giving a wide range of standard height and radius options and available customisation. Particularly suited to situations with physical constraints (headroom, handrails, pipework etc.) with a wide range of configurations available. Designed to comply with manual handling regulations and to avoid assembling the davit at height. N.B: TYPE W provides Winch & Shackle lifting points. TYPE S provides Shackle lifting only T-DAVIT Information: • Integrated wheel carrier for reduced manual handling Options & Upgrades: • Beam radius adjustment Notified Body Approval SGS UK (0120); Patented design. • GOODS WLL Up to 500kg (see table on next page) • PERSONNEL WLL Configurations available up to 250kg positioning, 150kg fall arrest* • 1 PERSON FALL ARREST EN795:2012* certified - as part of an EN363 compliant system. In conformity with AS/NZS 5532:2013* and ANSI Z359.18-17** • ROPE ACCESS Conforms to IRATA International Code of Practice for industrial rope access* • ATEX All models suitable for use in ATEX Zone 2 explosive atmospheres. ATEX Zone 1 is available as an upgrade • LIGHTWEIGHT & PORTABLE Manual handling compliant Reduced maintenance costs Bagged for easy transportation and storage • RAPID ASSEMBLY Assembly and operation by 1 person, no tools required - just 2 main components • RADIUS ADJUSTMENT Operational radius up to 3000mm - subject to WLL reduction (1600mm maximum for EN795) • EASE OF ROTATION 360° rotation under full load with fingertip control • CORROSION RESISTANT Clean anodised finish to increase wear resistance • UNIVERSAL KINGPIN Mates with all 65mm REID sockets (or sleeves for existing sockets) Also suitable for use with socket extensions • SPECIFICATIONS 2 lifting positions as standard (A&B) - (see table) Twin shackles for index lifting and/or attachments for winching *Applies to radius up to 1600mm **Applies to radius up to 1000mm
