Roll Out - EZ-B v4

This Roll Out is for the E-01 EZ-Bv4 Main Board and E-15 EZ-Bv4 WiFi Board reference designs and covers everything you need to create a WiFi Robot Controller Product. The EZ-Bv4 can be controlled over WiFi using the graphical EZ-builder software on your PC, laptop, tablet or mobile device. The EZ-B Main Board has an STM32F205 ARM Cortex-M3 Microcontroller that provides servo, digital i/o, real-time audio streaming and more! Together with the top WiFi board it has 5 volt tolerant I/O, energy efficient digital switching power supply, Wi-Fi connectivity with security, embedded web server, telnet server, amplified digital audio with speaker, 3 x I²C ports, 3 x UARTs, 24 multi-use servo/digital/serial ports, 8 analog ports, and integrated video port. The most unique feature of the EZ-Bv4 is that it's a complete, all-in-one, robot control solution. It has built-in amplified audio, dedicated camera port for video, wireless network communication, digital/UART ports for motor control, analog/I2C ports for sensory input, and it's all in a pocket sized form factor. This Roll-out includes: 1. Feature set 2. Hook-up guide for Power, Digital Sensor, Analog Sensor, I2C, Camera, and Speaker 3. Using related Synthiam EZ-Builder Software Behavior Controls 4. Schematic overview 5. Bill of Materials (BOM) overview 6. Custom firmware location Synthiam EZ-Bv4 information page: https://synthiam.com/GettingStarted/B... Synthiam EZ-Builder Software: https://synthiam.com/Products/EZ-Builder Featured Synthiam Behavior Controls: https://synthiam.com/Products/Control... https://synthiam.com/Products/Control... https://synthiam.com/Products/Control... https://synthiam.com/Products/Control... https://synthiam.com/Products/Control... GitHub Reference Designs: https://github.com/synthiam/E-01_EZ-B... https://github.com/synthiam/E-15_EZ-B...
