01B2SER_1000 Counterbalanced manual crane

The 01B2SER_1000 counterbalanced swivel crane has been designed to be easy to use and safe. The ballast with ergonomic handles and the bearing slewing ring ensure smooth and effortless rotation. The 200 kg load capacity and 360° rotation make it a versatile and reliable tool for a wide range of applications. Thanks to the push-button radio control equipped with a potentiometer, the 01B2SER_1000 mini crane offers millimetric precision in the lifting, lowering and extension movements of the boom. The 01B2SER_1000 mini crane is equipped with an electric extension with a stroke of 1000 mm and, with the addition of a mechanical extension available as an optional, it can reach a maximum overhang of 1910 mm. The crane is equipped with four nylon wheels: two pivoting, equipped with bumpers and parking brake, and two fixed mounted on ball bearings. This configuration ensures exceptional stability and precise maneuverability even under heavy load conditions. The frame, made of painted steel for greater resistance to corrosion, is equipped with specific supports for lifting with a forklift, making it easy to move the crane in any working environment. The hydraulic system is equipped with a lock valve that prevents the load from falling in case of accidental breakage of the pipes and a rough valve that prevents overloading of the crane. It represents the most cost-effective and flexible solution for lifting and transporting loads in several applications such as machining centers and machine tools, delivery to assembly lines, assembly operations, goods handling. Thanks to its compact dimensions this counterbalanced crane is easily maneuverable even at full load and can be moved effortlessly in confined spaces. All components are made in Italy to ensure the highest construction quality and the absence of defects. External battery charger. Powered by lead acid battery, this crane can be also equipped with maintenance free AGM sealed battery or Lithium battery. Multifunction display showing charge level, battery voltage and operating hour meter. Model 01B2SER_1000 is the most popular model for awkward placements from the ground onto 3D machines, lathes, over perimeter protections, narrow openings, etc., and thanks to its 360° rotation, in all those applications where there is no space to move the load with a forklift or other large sizes lifting equipment. NO INSTALLATION REQUIRED: All our cranes are counterbalanced which means that a load can be picked & carried without using outriggers. Just turn the key on to get the cranes working. Our cranes come fully assembled and are ready to use. No installation = zero additional costs and waste of time. SAFETY AT THE WORKPLACE: All the industries do have safety risks but the management should devote their time to think and strategize the things that what safety precautions are required in their company to make sure that their workers are safe enough for all the time. Our cranes are the appropriate tool to avoid all risks involved with manual handling of loads. PRECISE POSITIONING: The use of mini cranes, especially the ones equipped with a progressive speed control, lead to a better accuracy when positioning a load or a component that must be handled with care such as molds, engines,etc.
