Example 3.8 How to create a local coordinate system to define material orientations in Abaqus

Example 3.8 shows you how to create a local coordinate system, in this case, used to specify the orientation of the lamina with respect to the global coordinate system. In the process, we learn how to use a Datum Point, and to use the Tools menu. Additional details in the textbook "Finite Element Analysis of Composite Materials Using Abaqus." Multilingual CC available. Textbook: https://www.amazon.com/exec/obidos/AS... Table of Contents: 00:00 - Introduction 00:12 - Description 00:31 - Part 00:51 - Property 01:07 - Tools Datum CSYS 01:59 - Assign 02:26 - Section 02:58 - Assign section to part 03:09 - Assembly 03:27 - Step 03:40 - BC SS1-xx 04:39 - BC SS1-yy 05:21 - Load 05:53 - Mesh 06:35 - Job 06:52 - Results 07:09 - End card
