How Cone Mill works, Conical Screen Mill in Pharma - Senieer

#conemill In this video, I’m going to show you all of the components of the Table Lab cone-mill and how to disassemble that and automatic operation system. Disassemble process: 1)First, disassemble Clamp it also calls castell key which is used AISI304 Stainless steel 2)Disassemble the coupling sleeve between the head and motor 3)Take off the silicone pad 4)Disassemble Clamp it also calls castell key which is made by AISI304 Stainless steel 5)Disassemble manual fly gate 6)Take off the silicone pad 7)Disassemble big Clamp 8)Open the safety interlock 9)Take out a Compression nut 10)Take off the Square impeller 11)Take off round hole sieve 12)Disassemble big Clamp and coupling sleeve between head and motor 13)Disassemble Clamp 14)Disassemble the main body Now time to assemble the part. It is similar to the disassembling part. During this assembly process, we have to make sure every part is properly fixed because no gap is allowed between two parts, and every part assembles properly especially the sieve and impeller, after that, we can find a uniform shape of materials, without gap mentation we cannot find uniform shape. So, we have to focus on. Make sure proper gape between two parts. At the same time, we have to remove leakage so we used in silicon pad inside the two parts. One of the key parts is the flying manual valve, by using a valve then we can control the material’s charging flow to the main body. Finally, we have to focus on every assembly part is fixed properly. Because there is no gap allowed between all of the parts. Now it is time to show the controlling part. We can see here is a PLC control and touch screen. We can see the rotation of the impeller and charging materials. it is time to adjust the rotation of the motor which is rpm, after setting the rpm we can see our final products, and also, we can change the rpm. SENIEER Table Lab cone-mill is the best choice for your R&D and Product development. A conical mill is a machine used to reduce the size of material in a uniform shape. SENIEER cone mill is an alternative to the hammermill or other forms of grinding mills. As the name implies, the conical mill varies in diameter from where the feed enters to where the product exits. The conical mill operates by having the product being fed into the mill by gravity or vacuum. A rotating impeller forces the material outward to a conical screen surface, where it is sized and passed through the openings in the screen. Once finished, the product simply drops through the milling chamber to a receptacle underneath. Conical mills come in a variety of sizes from tabletop lab models to full-size high-capacity machines for use in processing large quantities of material, and the impeller and screen can be customized for each use. The machines can be used not only to reduce the size of particles, but also for deagglomeration, sieving, dispersion, and mixing. Link: https://www.senieer.com/comill-conica... Whatsapp: +8613637787586 Email: sales@senieer.com
