Function Generator Explained - Includes how to use sweep and high-z for Agilent 33220A

In this video we cover the basic functions of the Agilent 33220A waveform generators (function generator). Basic cables and connectors are shown. The generator will be measured using an oscilloscope. We cover how to change basic settings including: frequency, amplitude, waveform, offset, sweep, high z. We do Items shown in video - Function generator - https://amzn.to/38yEuj3 Oscilloscope - https://amzn.to/3KeCSsn Timestamps 0:00 Intro 0:40 Connections 1:06 Startup 1:16 Default settings 1:35 Measure Settings with an Oscilloscope 2:00 Changing basic settings (Frequency, Amplitude, and Offset) 2:48 Change Amplitude 3:46 Change Frequency 4:27 Change waveform 5:03 DC Offset 5:37 Turning off the device 5:55 Sweep 7:45 Probe Considerations 8:10 High Z considerations Stay connected! Youtube Channel -    / @htmworkshop   Instagram -   / htmworkshop   Twitter -   / htmworkshop   Facebook -   / htm-workshop-101784815596164   Website - HTM-workshop.com
