How to use the BK Precision Oscilloscope for Beginners

Introduction to Oscilloscope BK Precision 2542B-GEN Digital Storage Oscilliscope and Generator. The video covers a variety of topics including how to start up your scope, restore default settings, using channel inputs, how to use probes, how to measure the calibration signal, using the auto button, how to change offset, channel voltage, modify the timescale This is a 100 Mhz oscilliscope - in general you should not measure anything with a frequency greater than 20 MHz (your o-scope bandwidth should be 5 times greater than the highest frequency you will measure). If your into o-scopes - check out this t-shirt https://www.etsy.com/listing/12023511... Timestamps 0:00 Introduction 1:21 Channel 1 and Channel 2 Controls Overview 1:55 Start up - Beginning of using your scope 2:10 Difference between o-scopes and handheld meters 3:00 How to restore factory settings 3:56 Probes 6:08 Measuring calibration signal 7:35 Adjusting the oscilliscope displayed voltage in reticle 9:30 Adjusting timescale 10:46 What set's oscilloscopes a part 11:20 Taking a measurement
