EMU (Expandable Multi-material Unit) Filamentalist and Stepper Assembly Guide

Part 1 of the EMU (Expandable Multi-material Unit) assembly video series. The EMU, the Expandable Multi-material Unit is a modular, flexible, upgradable, reliable and service-friendly MMU designed around the proven filamentalist V3 platform and made for Voron and klipper based printers. The EMU supports any number of lanes and base configurations; whether it is a single lane setup to assist filament loading, a dual lane configuration for endless spool, or a multi-lane, multi-box setup for multi-material printing. It is also expandable, with no re-printing of parts required when upgrading from a 2 lane to a multiple lane setup. This video focuses on assembling the integrated filamentalist & stepper assembly. This is the heart of the system, feeding filament to the toolhead and rewinding back to the spool on unload. Project GitHub: https://github.com/DW-Tas/EMU Chapters: 00:00 Intro 00:06 Heatset inserts installation 01:05 ECAS fittings installation 01:41 Stepper assembly 03:46 Tensioner mount assembly 04:21 Pre and post stepper sensor assembly 06:18 BMG gear alignment & stepper assembly fastening 06:43 Sensor wiring 08:06 Filamentalist body assembly 10:16 Filamentalist wheels and one way bearing assembly 14:41 Filamentalist tensioner adjustment 16:06 Bowden tube installation 16:50 BMG Tensioner assembly and calibration #voron #3dprinting #multimaterial #mmu
