Music reactive LEDs || Sound sensor - Arduino Connections & Coding || Techie Lagan

Music reactive LEDs || Sound sensor - Arduino Connections & Coding .... Hi guys, in this tutorial we will learn how to connect, code & use a sound sensor with the help of Arduino UNO Board..!! Also, you will learn how to make music reactive LED lights..!! =================================== Requirements:- 1. Arduino UNO - https://amzn.to/3MasK4x 2. Breadboard - https://amzn.to/37uxKlM 3. Jumper Wires/single stranded wires - https://amzn.to/3JV8NwZ 4. LEDs - https://amzn.to/3EkTpsG 5. Sound sensor - https://amzn.to/3OlSCMH =================================== Circuit Diagram - https://drive.google.com/file/d/1GRBx... Code Link - https://drive.google.com/file/d/1lVC-... Alternative code link: https://drive.google.com/file/d/16vdy... =================================== Note :- You must have observed that, while testing, the red led on sensor was glowing. Well, ideally the sensor led & externally connected leds should glow together i.e they must be in sync ! But if that doesn't happen, adjust the potentiometer in such away that external connected LED responses perfectly to music just as I did & just don't care about sensor light. :D =================================== Note:- The potentiometer on the sound sensor allows you to adjust sensitivity of the sensor. Changing sensitivity allows the LED to glow even at low sound levels & high sound levels. High sensitivity will enable the sensor even to detect the smallest sounds. Turn the potentiometer clockwise to increase the sensitivity & anti-clockwise to decrease the sensitivity. =================================== Connections of Sound sensor - VCC - 5V supply of Arduino GND - GND of Arduino D0 - Pin 3 on Arduino Connections of LED - Positive terminal - Pin 7 on Arduino (or any digital pin) Negative terminal - GND of Arduino 00:00 - Intro 00:11 - Materials Required 00:44 - Connections 02:35 - Adjusting Potentiometer 02:46 - Code 03:23 - Demonstration 03:55 - Outro Products I use: Laptop(HP pavillion 15): https://amzn.to/3LnHsFg Keyboard: https://amzn.to/3Ko2Mt0 Gaming Mouse: https://amzn.to/3KkFRyI Phone: https://amzn.to/38us6Ac Maono AU-400 Lavalier Mic: https://amzn.to/3OCyPJd Gaming Earphone(SpinBot BattleBudz) : https://amzn.to/3OFH07l =================================== Here are my social media links - Facebook Page - Instagram -   / techie_lagan   =================================== Thanks For Watching ✅LIKE ✅SHARE ✅ COMMENTS✅ SUBSCRIBE #SoundSensor #ArduinoProject #TechieLagan
