Soil Grinder SG 1 (VIBROTECHNIK)

See more: https://vt-spb.ru/catalog/dlya_istira... The SG 1 soil grinder is designed to grind dry soil samples without comminuting plant inclusions and stones. Soil comminution in the grinder occurs as a result of material particles being crushed by rollers. The grain size of the comminuted product is regulated by the size of the discharge grating openings and depends on the physical properties of the material. A soil sample is fed through the charging funnel to the comminution chamber, where it enters the space between the rollers and the discharge grate. When the gear motor is started, the forks and roller axle begin to rotate, and the rollers (both smooth and toothed) roll over the soil layer, gradually comminuting the sample. Soil particles are comminuted to 1 or 2 mm (depending on the grate installed) and pass through the opening in the grate to the receiving container. Solid inclusions (plants, stones) are not comminuted and remain on the grate without fouling the comminuted sample. Loading door dimensions – 145 х 140 (mm) Roller dimensions (Diameter x Width) – 55 х 28 (mm) Number of smooth/toothed rollers – 4/4 Maximum initial material grain size – 20 (mm) Size of discharge grate openings – 1 and 2 (mm) Average comminuted product particle size with grate with 1 mm opening – 1 (mm) Maximum output – 20-40 (kg/hour) Gear motor power – 0.75 (kW) Shaft rotational speed – 75 (rpm) 50 Hz supply voltage – 380 (V) Overall dimensions (Length x Width x Height) – 640 х 465 х 720 (mm) Weight – 60 (kg) Roller material – tool steel AISI 1066, AISI 01, DIN 150Cr14
