Robotic Sand Control Screen End Ring Welding & Shrink Fit Assembly System

• Pipe is accumulated on the pipe racks • Accumulated pipe is separated and rolled up to the singulator and drop down rack section • Drop down rack section lowers the pipe onto a roller conveyor • Pipe is conveyed longitudinally to a 40’ long fit up section • Pipes may receive one or two screens depending on the length • Slip on collars are placed on each end of each screen and tacked into place • Fitted pipes are conveyed onto the next conveyor section • End of the pipe is captured by the headstock for servo rotation of the fitted pipe • Two methods are considered for welding the fittings to the pipe and capturing the rib wires move the welding and heating units along the length of the pipe • Welding torch, wire feeder, power supply, cooler, wire spool and fuel gas powered heating equipment are all transporter mounted. The control & other HMI are stationary and a long pendant cord is needed to reach the length of the pipe move the pipe along in front of the welding and heading units • The headstock, steady rest, and tail stock are transporter mounted and move the pipe along in front of the process equipment. • The welding torch, wire feeder, power supply, cooler, wire spool, fuel gas powered heating equipment, controls, short pendant & other HMI are stationary • This approach also opens up the possibility of using induction heating as opposed to fuel gas • Completed pipe is conveyed back to the racks and continues to accumulate on the racks until it is ready for pickup.
