MSX DC600 - The cartridge based DC-600 reimagining of the TDC600 Floppy controller for the MSX

EP54 - The MSX DC600 from SKOTII ( The creator of the JFF MSX ) is a clone of the cartridge based TDC600 floppy controller for MSX computers. Here i assemble one and get it fired up with a gotek.... Please Note: Although the 1st board i built ( as in this video) had some issue with the clock circuit, The 2 resistors and 138 chip i removed, I later re-used these and built a second board which worked perfectly with these components as per the BOM.... It seems that the floppy controller chip may be a bit variable in what they like, clock signal wise, Either way solution is easy, 2 resistors and / or 138.... SKOTII https://github.com/konkotgit/MSX-DC-600 ‪@skotii‬ Don't forget to check out the channels below 8BitRetroRefix    / @8bitretrorefix   Retro4u    / @retro4u   Josip Retro Bits    / @josipretrobits   8BitsInTheBasement    / @8bitsinthebasement   TimsRetroCorner    / @timsretrocorner   Retro Krazy    / @retrokrazy   Alices Retro Wonderland    / @alices.retro.wonderland   ....Also be sure to check out PCBWAY.COM for all your PCB & maker needs ...... Please use my referral link below to get $5 of FREE user credit !!! https://pcbway.com/g/7Ia2k6
