How do I install panels with the Multiblock 8 Zn from item? Variants explained step by step

This video shows four possible fastening options for panels in a construction with Profile Groove 8 using the item Multiblock 8 Zn as a tutorial. The Multiblock 8 Zn is particularly suitable for applications with high loads (max. 2,000 N transverse and max. 1,000 N longitudinal to the groove). It is ideal for designers, planners and fitters in industry who want to mount panels, cladding, protective screens, etc. on Profile Groove 8. The Multiblock offers a choice of a through-hole or a square nut, which is secured against falling out by a spring washer. Video content on panel mounting with the Multiblock at a glance: 00:00 Intro The title image of the video shows a transparent panel mounted on profile groove 8 using the multiblock. 00:07 Multiblock is mounted in the profile frame The Multiblock is mounted in the frame using T-slot nuts and screws (hexagon socket wrench with a wrench size of 5 mm and a tightening torque of 15 Nm). The lateral distance between the Multiblock and the frame is approx. 100 mm. The Multiblock 8 Zn has various openings and an integrated square nut, which allow the panels to be mounted in a variety of ways. 01:06 Panel is mounted according to variant A The panel is inserted into the frame using four spacers (thickness: 1 mm). This creates a gap of 1 mm between the panel and the frame. Variant A: The panel is fastened using through holes with a diameter of 6.6 mm and Button-Head Screws M6x16 (hexagon socket wrench with a wrench size of 4 mm and a tightening torque of 2.5 Nm). The opening in the multiblock used for this is marked in the video. 01:48 Panel is mounted according to variant B Variant B: The panel is fastened using through holes with a diameter of 9 mm, Button-Head Screws M8x16 and nuts ISO 4032 M8 (hexagon socket wrench with a wrench size of 5 mm and a tightening torque of 2.5 Nm). The opening in the multiblock used for this purpose is marked in the video. 02:19 Panel is mounted according to variant C Variant C: The panel is fastened using threaded holes M6 and Hexagon Socket Head Cap Screws DIN 912 M6x16 (hexagon socket wrench with a wrench size of 5 mm and a tightening torque of 2.5 Nm). The opening in the multiblock used for this purpose is marked in the video. 03:03 Panel is mounted according to variant D Variant D: The panel is fastened using threaded holes M8 and Button-Head Screws M8x10 (hexagon socket wrench with a wrench size of 5 mm and a tightening torque of 2.5 Nm). The opening in the multiblock used for this is marked in the video. Finally, the spacers are removed again. The following products were used in the video: 1. Multiblock 8 Zn: http://i24.ws/37323 2. T-Slot Nut V 8 St M8, bright zinc-plated: http://i24.ws/48048 3. Button-Head Screw M8x18, bright zinc-plated: http://i24.ws/8000002 4. Button-Head Screw M6x16, bright zinc-plated: http://i24.ws/8000063 5. Button-Head Screw M8x16, bright zinc-plated: http://i24.ws/8000019 6. Nut ISO 4032 M8 7. Hexagon Socket Head Cap Screw DIN 912 M6x16, bright zinc-plated: http://i24.ws/65509 8. Button-Head Screw M8x10, bright zinc-plated: http://i24.ws/8000017 ► MORE TIPS AND TRICKS ON ITEM PRODUCTS: https://academy.item24.com ► DESIGN ONLINE NOW: https://tools.item24.com/DEen/tools/e... ► If you enjoyed watching our video or want to tell us what you think, please leave us a comment. --- For more information and to check out example applications showing how you can make your production operations more efficient, subscribe to our channel, or visit us at: ► Website: https://de.item24.com/en ► Shop: https://www.item24.com/en-de/ ► Blog: https://blog.item24.com/en/ ► LinkedIn:   / item-industrietechnik-gmbh   ► Facebook:   / itemworldwide   ► YouTube:    / item24com   #assembly #multiblock #panel #fastening The video was recorded on 2022-07-27 10:00:00.000 and is valid until further notice. The description was last updated on 2025-07-15 15:30:00.000. This video was produced by the manufacturer of the products used: item Industrietechnik GmbH Friedenstraße 107-109 42699 Solingen Related videos: Clamp-Multiblock 8 PA:    • How do I install panels without tools usin...   Multiblock 8 PA 0/5 mm:    • How do I install perforated sheets with th...   Multiblock 8 PA:    • How do I install panels with the Multibloc...   Multiblock 8 PA with Safety Fastening Set Multiblock 8:    • How do I mount panels with the Safety Fast...
