How to Calculate the Components – Components and Resultants Parallelogram Rule – Statics Problem 4

SUBSCRIBE to my channel for similar videos and problem walkthroughs. Make sure to leave a LIKE if this video was helpful. Please check out videos on the channel, as we cover many different topics. In this video, we find the component forces and their directions from the given resultant vector that would result from these two forces. This problem is resolving 1 resultant force to make two component vectors via the Parallelogram Rule. Problem statement: A barge is pulled by two tugboats. If the resultant of the forces exerted by the tugboats is a 5000 lb force directed along the axis of the barge, determine the tension in each of the ropes knowing that alpha is 45 degrees. Problem walkthrough steps: Draw a quick free body diagram Form a parallelogram by copying and pasting the component forces Draw in the resultant from corner to corner -Calculate the angle opposite the resultant force -Use the law of sines to find the unknown components which are the tension forces in the cables Topics of this problem include: Free Body Diagram (FBD) Solve a statics components and resultants problem via the Parallelogram Rule. Resultant from 2 component forces Resultant from 2 component vectors Vector Addition Force combination Vector combination Vector Mechanics Law of cosines Law of sines Determining resultant angles Beer Johnston sample problem 2.2 Engineering statics 2D components and resultants problem 4 Professor Engineer Professor_Engineer
