Proteus Tutorial - 6 || Motor speed control using 555 timer IC

#circuitdesign #proteus #electronic #555ic #motors In this video we have learned about control the motor speed using 555 timer IC. It is working become a oscillator ( frequency generator). If we control the frequency , we can able to control the motor speed. It is the one of the method to control the motor speed. Software : Proteus 8 professional components used : 1) 555 Timer/oscillator IC 2) 1k Resistor 3) 50k potentiometer 4) 1N4001 diode 5) 1N4007 diode 6) BD 139 transistor 7) DPDT switch 8) 12v dc Motor 9) 0.01uF and 0.1uF capacitors previous video link : 1) Proteus Tutorial _1__Control LED with switch using 7805 5v regulator link:    • Proteus Tutorial _1__Control LED with swit...   2) proteus tutorial 2 || simple 12 v battery charging level indicator circuit design link:    • proteus tutorial 2 ||  simple 12 v battery...   3) proteus tutorial 3 || ammeter and voltmeter interface link:    • #proteus tutorial 3 || ammeter and voltmet...   4) Proteus tutorial 4 || Simple circuit for Virtual oscilloscope connection link:   • Proteus tutorial 4 || Simple circuit for V...   5) Proteus tutorial for beginners || tutorial - 5 || Blink the LED using 555 timer IC link:   • Proteus tutorial - 5 || Blink the LED usin...   Telegram Channel link: https://t.me/mr_science_bro
