How to make a Glass PCB at home

In this video, I’ll walk you through the entire process, from gathering materials to the final product. We start by discussing the necessary materials, focusing on the importance of high-quality copper tape and a clean glass surface. We then move on to the preparation stage, where we clean the glass thoroughly and cut the copper tape to the required dimensions. Next, we carefullyf apply the copper tape to the glass, ensuring it adheres well and is smooth without any air bubbles. We also cover how to create your desired circuit design on the glass using the copper tape. Finally, I will demonstrate how to connect your electronic components to the copper tape to complete your PCB. I will also share some tips and tricks for troubleshooting common issues you might encounter during the process. Project files: https://github.com/MakersFunDuck/Glas... Items required: Copper Tape (make sure it does not have conductive adhesive othervise it will not work): https://amzn.to/42G00ub https://s.click.aliexpress.com/e/_opx... 10 cent MCU (CH32v003) +debugger: https://amzn.to/49cpphv https://s.click.aliexpress.com/e/_oCy... iron cloride: https://amzn.to/3I2ZKLY
