Signals & Systems #16 | CT Graphical Convolution

Many academic videos are categorized here: https://AcEdumy.com Learn graphical convolution for continuous-time signals! We derive the general formula u(t-a)*u(t-b) = r(t-(a+b)) and work through a complete rect*rect example, identifying five distinct time regions. An algebraic verification confirms the result. Topics covered: Shifted step convolution: u(t)*u(t-2)=r(t-2), u(t-2)*u(t-3)=r(t-5) General formula: u(t-a)*u(t-b) = r(t-(a+b)) Graphical convolution method: flip, shift, integrate overlap Complete example: rectangular pulse convolution → trapezoid Five time regions: no overlap, partial entry, full overlap, partial exit, no overlap Algebraic verification using distributive property Part of the Signals & Systems series based on ECE 218. Lecture 7 — Part 2 of 2. #SignalsAndSystems #Convolution #GraphicalConvolution #ECE218 #AcEdumy
