Injection molding machine - Industrial Solutions

HYDRAULIC INJECTION MOLDING MACHINE – 330 TON – USED – YEAR: 2007 Clamping force (closing/opening): 3300 / 640 kN Moving platen stroke: 640 mm Platen dimensions: 990 × 930 mm Distance between tie bars: 660 × 600 mm Minimum mold height: 220 mm Maximum mold height: 730 mm Ejector force (power mode): 86 kN Ejector force (fast mode): 54 kN Ejector stroke: 220 mm Plasticizing screw diameter: 80 mm – barrier screw L/D ratio (Euromap No.1): 20 Theoretical injection volume: 1690 cm³ Effective shot weight (PS): 1560 g Injection rate: 609 cm³/s Maximum material pressure: 1560 bar Plasticizing capacity (PS): 84 g/s Screw torque: 2290 Nm Maximum screw speed: 297 rpm Barrel heating power: 24 kW Heating zones: 4 + 1 Nozzle contact force: 162 kN Electric motor power: 45 kW Hydraulic oil capacity: 500 L Total installed power: 69 kW Machine weight: 13,500 kg Machine dimensions: 7440 × 1700 × 2570 mm The machine is supplied with user manual, spare parts exploded diagrams, and CE certificate.
