How to make charging circuit for Inspectorobot with LED Indicator |

In this #Arduino and #Inspectorobot tutorial, I show how I set up a proper DC power jack and charging indicator LED for my DIY robot. ⚠️ First, I demonstrate what happens when you connect an LED directly to a 12V charger (yes, it burns out!). ✅ Then, I explain the importance of using a resistor with the LED, and why a diode is essential to prevent reverse current back to the LED or charger. This video is perfect for beginners learning about basic charging circuits, LED protection, and safe DIY wiring in Arduino-based projects. Components Used: (Amazon affiliate links: I get a commission on your purchase) Red LEDs: https://amzn.to/4jHOXrG 1k ohm resistor: https://amzn.to/4jbYXcJ DC Jack: https://amzn.to/4jkO48D 12 Volt Charger: https://amzn.to/4jkO48D Diode: https://amzn.to/4jrkYnZ 🔌 Topics Covered: Using 12V DC charger safely Choosing the right resistor for LEDs Adding diode to protect circuit Preventing damage in power circuits Power management in DIY robot builds 👉 Stay tuned for more #ESP32 and #robotics content from my Inspectorobot series. 🔧 Full Inspectorobot Playlist:    • Inspectorobot DIY ESP32 Cam Car   📥 Subscribe for more DIY tech builds and tutorials!
