Connecting plates for railings / steel design with Autodesk Inventor, SolidSteel parametric Tutorial

In this tutorial we show how to create and use parametric connection plates for your custom railing templates. The video is a follow-up video to the railing tutorial that should be viewed first, you can find it here:    • Make your own railing templates to use in ...   The detailed tutorial on manual bolting mentioned in the video can be found here:    • Manual bolting in structural steel design ...   Chapters 0:00 Introduction 0:19 Starting point 0:51 Editing the Sketch 1:13 Editing the Parameters 2:10 Place connector plate in SolidSteel 2:51 Editing plate Sketch on part level 3:30 Editing plate Parameters 4:03 Pattern 4:49 The Learn Railing feature 5:14 Setting the parameters for the Railing dialog 5:33 Adding the new railing to the database 5:43 Testing the new railing template 7:04 Manual Bolting 7:53 Detailing the bolted connection 8:15 Adding complete bolting with one click Good success and if you have any questions, just write them in the comments or contact us via   / apps-for-autodesk-inventor-by-klietsch-gmbh   https://klietsch.com/inventor You can download the free Express version of SolidSteel parametric from our website or from the Autodesk App Store (https://apps.autodesk.com/INVNTOR/en/....
