Multispan MS 1248U: 8 channel temperature scanner

This video provides a complete guide on the setup, connection, and programming of the Multispan MS 1248U, an 8-channel input temperature scanner. The tutorial demonstrates the electrical wiring for power and sensor inputs (J-type, K-type, and Pt100). It then walks through the configuration menu, explaining how to set the scrolling (scan) time, skip unused channels, select the appropriate sensor type for each channel, and, most importantly, configure the advanced 4-relay output grouping facility. Finally, the video covers setting alarm set points, applying channel offsets, and setting up the integrated USB data logging feature to store up to 8000 readings, including setting the real-time clock and data logging interval. Video Chapters: 00:00 Introduction to MS 1248U Temperature Scanner 00:11 Physical Connections & Power Wiring 00:25 Connecting Temperature Sensors (J, K, Pt100) 00:57 Understanding Relay Outputs (4 Relays for 8 Channels) 01:32 Setting Scan Time & Channel Skip/Unskip 02:11 Configuring Sensor Type for Each Channel 02:42 Setting up Relay Output Grouping (Program Entry) 02:51 Group 1 Configuration (Channels 1, 2, 3) 03:32 Group 2 Configuration (Channels 4, 5, 6) 04:00 Group 3 Configuration (Channels 7, 8) 04:19 Setting Alarm High/Low/Trip Set Points 04:49 Applying Channel Offset 05:36 Configuring USB Data Logging Facility 06:08 Setting Real-Time Clock & Date 06:32 Conclusion #Multispan #MS1248U #TemperatureScanner #TemperatureController #DataLogger #IndustrialAutomation #Pt100 #Thermocouple #Instrumentation
