Unwinding a tiny 6kV xenon trigger transformer

I've used these in the past, and marvelled at how they can withstand such a high voltage in such a small component. I decided to take one apart to see how it's made. I ended up taking more than one apart. The construction is surprisingly simple, with a very retro alternative to resin potting. The alternative triggering circuits I mentioned sometimes use the thyristor pulling the transformer common connection to the zero volt rail, or put the capacitor where I drew the thyristor and a sidac in series with the primary. I dug out a more accurate set of calipers and remeasured the wires. Both transformers had a 0.28mm diameter (29AWG?) primary wire and a 0.12mm diameter (36AWG?) secondary wire. If you enjoy these videos you can help support the channel with a dollar for coffee, cookies and random gadgets for disassembly at:-   / bigclive   (extra streams and channel interaction) Or alternatively:- http://www.bigclive.com/coffee.htm This also keeps the channel independent of YouTube's advertising algorithms allowing it to be a bit more dangerous and naughty. #ElectronicsCreators
