TELEFUNKEN Elektroakustik TF29 TF39 Vacuum Tube Change Instructions TF29 TF39 скачать в хорошем качестве

TELEFUNKEN Elektroakustik TF29 TF39 Vacuum Tube Change Instructions TF29 TF39

TELEFUNKEN Elektroakustik TF29 TF39 Vacuum Tube Change Instructions TF29 TF39 PROCEED AT YOUR OWN RISK! Tube microphones are fragile and can carry 'shock-worthy' voltages. We are not responsible for the well-being of you or your microphone. Please read all written instructions before proceeding! BEFORE YOU START: Turn off your power supply and disconnect it from the power outlet. Disconnect the microphone from the tube microphone cable and power supply. We recommend leaving the microphone unplugged for at least an hour before starting. We strongly recommend wearing rubber gloves, like in the video! Grease from your fingers can impact the operation of your microphone. If you are uncomfortable with doing this, please contact us. 1. Hold the microphone by the body tube and remove the base ring by turning it counterclockwise until fully unthreaded. 2. Set the base ring aside and slide the body tube off the microphone. 3. Lay the microphone flat on a stable surface. 4. With one hand, secure the tube socket. With the other hand, carefully pull the tube straight out, gently rocking it side to side if needed. 5. Remove the tube damper ring from the old tube and set the tube aside. 6. Remove the new 5654W tube from its box and visually inspect the pins to ensure they are straight. 7. Install the tube damper ring onto the new tube. 8. Locate the pin gap on the tube and the corresponding opening in the tube socket. 9. With the microphone flat, secure the tube socket with one hand and insert the new tube with the other, aligning the gaps. 10. Push firmly until the tube is fully seated and flush with the socket. 11. Locate the notch on the body tube and the notch on the microphone’s top plate. 12. Slide the body tube back over the microphone, aligning the notches. 13. Thread the base ring back on by turning it clockwise and tighten securely. https://www.telefunken-elektroakustik... https://www.telefunken-elektroakustik...
