TELEFUNKEN Elektroakustik TF47 Vacuum Tube Change Instructions - How To Change The Vacuum Tube TF47

TELEFUNKEN Elektroakustik TF47 Vacuum Tube Change Instructions - How To Change The Vacuum Tube TF47 PROCEED AT YOUR OWN RISK! Tube microphones are fragile and can carry 'shock-worthy' voltages. We are not responsible for the well-being of you or your microphone. Please read all written instructions before proceeding! BEFORE YOU START: Turn off your power supply and disconnect it from the power outlet. Disconnect the microphone from the tube microphone cable and power supply. We recommend leaving the microphone unplugged for at least an hour before starting. We strongly recommend wearing rubber gloves, like in the video! Grease from your fingers can impact the operation of your microphone. If you are uncomfortable with doing this, please contact us. 1. Hold the microphone by the body tube and remove the base ring by turning it counterclockwise until fully unthreaded. 2. Set the base ring aside and slide the body tube off the microphone. 3. Lay the microphone flat on a stable surface. 4. Using both hands—one on the PCB mount and the other on the rubber tube grommet—carefully pull the tube upward and out of the PCB socket and metal bracket. 5. Remove the rubber tube grommet, noting its original position, and set the old tube aside. 6. Remove the new 5840W tube with PCB mount from its box and visually inspect it for defects. 7. Install and position the rubber tube grommet onto the new tube, placing it near the top of the tube between the PCB mount and metal bracket. 8. Seat the rubber grommet into the metal bracket and align the PCB mount with the socket. 9. Carefully press the tube into position, ensuring no pins are bent and the assembly is fully seated. 10. Locate the notch on the body tube and the notch on the microphone’s top plate. 11. Slide the body tube back over the microphone, aligning the notches. 12. Thread the base ring back on by turning it clockwise and tighten securely. https://www.telefunken-elektroakustik...
