Planning for private 5G and LTE networks in the CBRS band with RadioPlanner 3.0

Get free trial at https://www.wireless-planning.com Time codes 00:00 - Intro 00:33 - DTM, Clutters, Map Layers and Base maps 02:14 - Main System Parameters 05:30 - User Equipment (UE) and Base Station Parameters 07:07 - Propagation Models 07:42 - Prediction Types 07:57 - Received Power 09:15 - Best Server 09:34 - Area with Signal above Both Base and Mobile Thresholds 10:15 - RSRP 10:50 - RSRQ 11:12 - C/(I+N) Ratio 12:15 - Maximum Throughput 12:49 - Number of Servers 13:09 - Point Analysis 14:00 - Compare Coverage Menu 15:17 - Save Coverage 16:35 - Reports RadioPlanner 3.0 is a planning tool for various types of networks, including: LTE / 5G (NR) mobile and fixed wireless access (FWA) networks Public safety land mobile networks: P25, TETRA, DMR, dPMR, NXDN Wireless IoT LPWAN networks: LoRa, SigFox, NB-Fi Precision agriculture systems Terrestrial radio and television broadcast networks: ATSC, DVB-T, DVB-T2, ISDB-T, DTMB, DAB, DAB+ Air-to-ground communication and radio navigation systems operating in VHF, UHF, and microwave frequencies: UAV (Drone) Control, Air-to-ground radio, ADS-B, VOR, DME RadioPlanner 3.0 uses propagation models: ITU-R P.1812-6 ITU-R P.1546-6 Longley-Rice (ITM) v1.2.2 Okumura-Hata 3GPP TR 38.901 Combined ITU-R P.528-3 + P.526-14 (for Ground-to-Air Radio only) RadioPlanner 3.0 performs various types of area studies for mobile networks: Received Power Best Server (Strongest Server) C/(I+N) Ratio Maximum Throughput Maximum aggregated Throughput Area with Signal above Both Base and Mobile Thresholds Number of Servers Coverage Probability RSRP for LTE and 5G RSRQ for LTE and 5G Simulcast Delay Spread Received Power with Simulcast Interference TalckOut and TalckBack Field Strength Area studies for terrestrial radio and television broadcast transmitters include: Field Strength at Receiver Location Best Server Simulcast Delay Spread FCC contours ITU-R P.1546-6 contours Population coverage Generation of list of localities covered by broadcasting Area studies for Air-to-Ground radio communication systems include: Received power Air-to-Ground link Received power Ground-to-Air link Best Server Air-to-Ground link RadioPlanner offers the following features: Work with multiple networks within a single project and view aggregate coverage predictions for maximum throughput and number of servers. Plan radio network frequencies while considering co-channel and adjacent channel interference. Display of path profiles with path losses and levels of carrier and interference on the co-channel and adjacent channels. Perform multipoint study of a group of CPE or IoT sensors (end devices), each with their individual parameters (antenna height, antenna gain, transmitter power, cable loss, and penetration loss) under varying deployment conditions. Import measured signal power level results for comparison with calculated values and adjust propagation model parameters. Compare multiple coverage prediction results. Save coverage prediction results as an interactive web page, KMZ file, PNG image, GeoTiff file, CSV file or as MIF file. Flexibly adjust base map layers and display custom vector layers. GIS features: Default digital terrain model (DTM) with 30m plane resolution, automatically loaded worldwide. Option to use custom DTM in GeoTiff format. Default clutter model with nine clutter types, automatically loaded worldwide. Created from OpenStreetMap (www.openstreetmap.org) and Global Forest Change projects. Option to use custom clutter in GeoTiff format. Common (e.g., OpenStreetMap, OpenTopoMap, US Topo) and custom base maps.
