Flags/Immediate/Move PCB – Superscalar 8-Bit CPU #41

I'm in the middle of moving all register-related chips of my homebrew CPU from breadboards to dedicated PCBs. In this video we design, layout, assemble, and test a PCB for the move and immediate buffer, the flags register, and a new 4 bit signed immediate mode. This provides a new home for a few odd bits and pieces that are currently scattered across the breadboards. This video series explores the concepts and techniques that make modern computer processors so incredibly fast and powerful. I build my very own 8-bit processor from individual logic gates and gradually evolve it to become a superscalar out-of-order machine. Along the way, we take a deep dive into contemporary computer architecture in a hands-on fashion and rediscover some of the foundations of modern computing. Previous Video:    • Register File Port PCB – Superscalar 8-Bit...   Series Playlist:    • Build a Superscalar CPU   GitHub Repository: https://github.com/fabianschuiki/supe... 00:00 - Intro 02:09 - Schematic 04:51 - 4 Bit Immediates 07:10 - Flags Register 09:01 - Layout 10:11 - Routing 11:49 - Silkscreen 13:18 - Assembly 15:10 - Soldering 15:58 - Testing 19:34 - Outro #homebrew #8bit #breadboard #superscalar #computer
